The NEW zeroing block ZB Pro Universal is a mounting base that allows you to mount a variety of accessories to a gun weaver base, and allows you to change the elvation and windage to zero it.
*New Universal Version allows you to mount your PARD NV008 without the need for the PARD Mount (ZB should be mounted in reverse)*
Zeroing is effortlessly done with traditional feel rifle scope turrets, which can be used with ease at any time and without any special tools.
It can zero a range of devices such as laser sights, illuminators, laser range-finding modules, telescopic sights and red dot sights. It can also be used to increase the elevation of a generic rifle scope, for shooters that need to cover targets close up to them.
Particularly effective with Yukon photon, PARD NV008/NV008 LRF or Leupold LTO Tracker Thermal Imager.
Other Applications
Thermal Monoculars
Optical Monoculars with crosshair
Night Vision Scopes
Technical specifications
Max weight to mount:
(recoilless)..................800 gr
(recoil up to 300G)......200 gr
Click Value Elevation.................1/4 MOA
Click Value Windage..................1/4 MOA
Max Adjustment Elevation........90 MOA
Max Adjustment Windage.........60 MOA
Weight.......................................200 gr
Dimensions................................145x65x27mm
Top Weaver Rail Length............... 90 mm
Locking Jaws Span......................54 mm
